External Roller-Shutter Systems and Accessories

Peaceful and comfortable living areas

It is designed to be used in old buildings, new constructions, high business centres, and residence applications with its insulation features, different colour options, and static resistance values.

  • Different sizes of polyurethane injected aluminum slats as 37 mm, 39 mm, 43 mm, 55 mm and 77 mm to ensure the desired visual effect and technical requirements of a single piece of roller-shutter.
  • Single/double walls for 55 mm, 60 mm, 77 mm and 100 mm aluminium extrusion slats
  • Special aluminium extrusion profiles for commercial usage with light transmittance holes and bulletproof strength
  • Aluminum boxes with the sizes of 137 mm, 150 mm, 165 mm, 180 mm, 205 mm, 25 0mm, 300 mm, 330 mm, 350 mm and 400 mm
  • Options for 45 degrees, 90 degrees, semi-circular and full circular in boxes and side covers
  • Options for 40 mm, 60 mm, 70 mm octagonal galvanized steel tubes and 102 mm round steel tubes
  • Integrated mosquito screen compliance
  • Assortment of accessories to complement the system
Product Dimensions

  • Profile Width: 70 mm
  • Number of Chambers: with 5, 6 chambers
  • Profile Class: B class
  • Seal System: Interior / exterior seal
  • Seal Type / Colour: TPE / Colour: Black or grey
  • Glass Thickness: 4, 14, 20, 24, 28, 29, 34, 40 mm

Product Performance

  • Profile Heat Transfer Coefficient: 1,45 W/m².K
  • Glass Heat Transfer Coefficient: 31 (-1,-6) (without interlayer)
  • Window Heat Transfer Coefficient: For door 2,53 W/m².K; For window 2,52 W/m².K
  • Air Permeability: 4
  • Water Isolation: For balcony door E1950 /E1050; For window E 900/E1050/9A
  • Wind Load Resistance: C5/B5; For window C2A5.C2/B3
  • Acoustics Performance: 31[-1;-6] dB

Application options

Please click on in order to see the PDF document which contains the application options related with the products.
